OP-MINI

Optical Probe OP-MINI optical probe senses light and IR pulses from LED, converts them into electric pulses.

/images/products/zenovate/OP-MINI.hero.png

Terminal Definition

OP-MINI Terminal Definition

Available Connectors

Get a Free Sample

With US$55 shipping cost, we ship requested free sample world wide.

Tehnical Specifications
Spectrum From IR to light
Connector Unterminated by default, with 10 connectors to choose from
Indicators 1 Indicator with dual display:
LED Green: synchronized with the LED light pulses.
Output Pulse output, synchronized with the LED light pulses.
Power DC +3.3~5V
Cable 1 meters(3.3 feet), extension available
Attachment 3M double side tape
Weight 40gr
Casing Material Polycarbonate
Protection Class IP65
Operating Temperature -30°C ~ 80°C

dimension

OP-MINI

OP-MINI Dimension
